Nickel Alloy Wireline Knuckle Joint Tool String 1.875 Inch

Ask Lasest Price
Brand Name :	Ruixin
Model Number :	1.25inch 1.5inch 1.875inch 2inch 2.125inch
Certification :	API Q1
Price :	130.00usd~
Payment Terms :	T/T
Supply Ability :	1 set 1 week
Delivery Time :	1 week

Add to Cart

Product Details
Company Profile

Nickel Alloy Wireline Knuckle Joint Tool String 1.875 Inch

1.875 inch Wireline Knuckle Joint Wireline Tool String

Wireline Knuckle Joint Wireline Tool String

Ⅰ. Introduction (B)

A wireline knuckle Joint is used to add flexibility to the tool string and it is effective in deviated wells. Whenever Stem and jar are not aligned or not moving freely it is impossible to operate tools. However, adding knuckle joint in a string this situation can be avoided. Knuckle Joints are run immediately below mechanical jar. For additional flexibility additional knuckle joints can be included between stem and jar.

Ⅱ. General Technical Parameters:

Size	Fishing neck	Connection	PN.
1.25＂	1.187＂	15/16UN	W08-01.07.00
1.5＂	1.375＂	15/16UN	W08-01.01.00
1.75＂	1.375＂	15/16UN	W08-01.02.00
1.875＂	1.75＂	1-1/16UN	W08-01.03.00
2.5＂	2.313＂	1-9/16UN	W08-01.09.00

Note: More customized parts are available upon request.

III. Structural features and use:

The wireline knuckle joint is composed of upper contact, connecting sleeve, ball stud, lower contact, etc. The upper contact and the inner ball socket of connecting sleeve constitute a marked inner spherical surface; the bottom of ball stud is connected with the lower contact. While swinging and rotating the lower contact, the outer spherical surface of ball stud can move freely in the ball socket.

Welcome to contact us at any time.
