5K 10K Slickline Tee joint Wireline Pressure Control Equipment

5K 10K SlicklineTee joint Wireline Pressure Control Equipment

5K 10K Wireline Tee joint Wireline Pressure Control Equipment

I.Introduction
The Wireline Tee joint is attached below the BOP,The Wireline Pumping tee connection thread is used to connect the wellhead manifold to provide a path for large flow. NPT thread hole on the other side of the tee body is a pressure release valve . After installing the pressure
release valve, it can be used for pressure relief to ensure safe operation.
II. General Technical Parameters
OTIS Quick Union

Bore	Work Pressure	Service	Connection	Seal Dia.
2.5＂	5K 10K	Std H₂S	5＂-4ACME	3.5＂
3＂	5K	H₂S	5＂-4ACME	3.5＂
3＂	10K	Std	5＂-4ACME	3.5＂
3＂	10K	Std H₂S	5-3/4＂-4ACME	4＂
2.5＂	15K	H₂S	5-3/4＂-4ACME	4＂
4＂	5K 10K	Std	6-1/2＂-4ACME	4.75＂
3＂	15K	Std H₂S	7-1/2＂-4ACME	5.5＂
5＂	5K	Std H₂S	8-1/4＂-4ACME	6.188＂
4＂	10K	Std H₂S	8-3/8＂-4ACME	5.25＂

III.Daily Maintenance

1．After use, the O-ring and seal should be replaced；
2．When not in use, should take the protector and brush the thread with anti-rust oil for storage.
