Blowout Preventer BOP 15000psi Wireline Pressure Control Equipment

Blowout Preventer BOP 5000psi 10000psi 15000psi Wireline PCE slickline PCE

Dual-Hydraulic operated Wireline Valve features two sets of Ram assemblies and hydraulic actuated system that allow fast,

safe and easy operation in a remote location. Dual Hydraulic Type 2 is suitable for slickline and braided line operation by changing its respective rams.

A BOP (Blowout Preventer) is connected with the top of either wellhead adapter or Christmas tree. Annular space around wireline or slickline will be sealed by closing lubricator valve when the wireline or slickline is still in the hole. Then the pressure in the well will be sealed to prevent blowout. Single ram BOP is usually used for wireline and double ram BOP is for wire stick accordingly. Three ram BOP (with shear ram) is also available. Max. work pressure is up to 105MPa (15,000PSI). BOP for standard and H2S services are both available with manual or hydraulic control methods.

Model	Work Pressure	Bore	Wireline / Slickline OD.	Control Method	Remarks
FZ6.3-35	35MPa	2.5"	0.125"	Manual/ Hydraulic	Single Ram
2FZ6.3-35	35MPa	2.5"	7/32"	Hydraulic	Double Ram
FZ7.6-35	35MPa	3"	0.125"	Manual/ Hydraulic	Single Ram
2FZ7.6-35	35MPa	3"	7/32"	Hydraulic	Double Ram
FZ10.2-35	35MPa	4"	0.125"	Manual/ Hydraulic	Single Ram
2FZ10.2-35	35MPa	4"	7/32"	Hydraulic	Double Ram
FZ6.3-70	70MPa	2.5"	0.125"	Hydraulic	Single Ram
2FZ6.3-70	70MPa	2.5"	7/32"	Hydraulic	Double Ram
FZ7.6-70	70MPa	3"	0.125"	Hydraulic	Single Ram
2FZ7.6-70	70MPa	3"	7/32"	Hydraulic	Double Ram
FZ10.2-70	70MPa	4"	0.125"	Hydraulic	Single Ram
2FZ10.2-70	70MPa	4"	7/32"	Hydraulic	Double Ram
FZ6.3-105	105MPa	2.5"	0.125"	Hydraulic	Single Ram
2FZ6.3-105	105MPa	2.5"	7/32"	Hydraulic	Double Ram
FZ7.6-105	105MPa	3"	0.125"	Hydraulic	Single Ram
2FZ7.6-105	105MPa	3"	7/32"	Hydraulic	Double Ram
FZ10.2-105	105MPa	4"	0.125"	Hydraulic	Single Ram
2FZ10.2-105	105MPa	4"	7/32"	Hydraulic	Double Ram

Welcome to contact us at any time.
