    Wireline Tool String Heavy-Duty Swivel Joint

    Ask Lasest Price
    Brand Name : Ruixin
    Model Number : 1.5inch 1.875inch 2inch 2.125inch
    Certification : API
    Payment Terms : T/T
    Delivery Time : 2-4 weeks
    Supply Ability : 1 set 2 weeks
    • Product Details
    • Company Profile

    Wireline Tool String Heavy-Duty Swivel Joint

    Wireline Tool String Heavy-Duty Swivel Joint

    I. Overview:
    Heavy-duty swivels are accessories for wireline work tools used to minimize the torsional effects of the wireline when running downhole facilities.
    II. Common technical parameters:

    SpecificationSalvage neckConnection thread
    1.5"1.375"15/16UN
    1.875"1.75"1-1/16UN
    2.5"2.313"1-9/16UN


    Note: Special specifications can be provided according to customer requirements.
    III. Structure:
    The heavy-duty rotary joint consists of an upper joint (piece 1), a bearing sleeve (piece 2), a mandrel (piece 3), and a lower joint (piece 4).
    Heavy duty swivel joints are designed to withstand shock loads and can be used under jars.
    Fourth, maintenance:
    When not in use for the time being, apply grease to the thread and place the wire protector.

    Welcome to contact us at any time.
